Details
Front & Rear Lights
A bright LED headlamp mounts to the frame illuminates the path ahead. Bright LED battery powered tail light is designed to make the bike more visible from the rear.
Ride Modes with Power Gauge
Ride modes are designed to ensure seamless functionality between electric and non-electric riding. The modes offered are Low Medium and High. To further the seamless functionality. Included on the head unit is a L (Low) to H (High) range with 4 Lights that are Lit up when particular power range is met.
Charging & Battery Range
The 36V 8Ah Lithium battery can be charged on-the-bike through a charging port conveniently located under the seat on the frame or easily removed for off-the-bike charging using the keys to unlock the battery. Use the capacity button on top of battery to see how much the battery is charged. Charging lights on the charger follows: red= charging and green=ready to access the adventure! The Removable, The 36V 8Ah Lithium battery delivers a real-world range of 10-75 miles, depending on ride-mode selection, terrain and how much pedal input the rider supplies.
Rear Rack
Compact comes loaded with a heavy duty rear rack can hold up to 50 ibs. The rack comes equipped with 3 elastic bands that will allow you strap your cargo on tight!
Motor- 250W brushless rear motor XOFO
Battery- 36V 8Ah Lithium battery Chinese cell
Charger- AC 100V -230V smart charger
PAS- RPM sensor, 6 magnetic points
Controller- Intelligent controller, Overload & low voltage protection
Display- 790LCD
Max speed- Class 2, 20 mph
Driving distance- Varies
Recharging time- 4-6h
Specs
Frame | Steel |
---|---|
Fork | steel rigid fork |
Rims/Wheels | Double wall aluminum alloy |
Tires | CST 20x1.75 |
Chainwheel | Single speed gear, 44T chain wheel |
Chain | KMC |
Stem | Steel, foldable |
Brake Levers | Aluminum alloy, with power cut off wire |
Brakes | F/R V brake |
Pedals | plastic, foldable |
Saddle | City comfort saddle, SR brand |
Seat Post | steel, foldable |
* Subject to change without notice.
Part Numbers
Option | MPN | Store SKU |
---|---|---|
Black / One Size | UBCCOMPACT1 | UBC29125599E |
